Facing Centering 1075
Features
- Four axis controller based machine (Siemens / Fanuc)
- BT-40 and BT-50 Cartridge Spindle
- 90 degree concept for easy loading and unloading
- Easy chip removal
- Total workpiece length accuracy +/-0.025
- Workpiece face runout accuracy 0.020 @Dia. 100mm
- Workpiece centering depth accuracy +/-0.015
- Hydraulic self centeric wise for job holding
- Roller Guideways
- Full machine guard
Technical Specifications
Capacity
| Max. Facing Diameter | mm | 100 |
| Max. Drilling Diameter | mm | 25 |
| Component Leoglh | mm | 150 to 750 mm |
| Drilling Slide Rapid Rate | m/min. | 25 |
| Milling Slide Rapid Rate | m/min | 25 |
Spindle
| Milling Spindle Nose | - | BT-40 |
| Drilling Spindle Nose | - | BT-40 |
| A.C Induction Spindle Motor Power-2Nos. | KW | 5.5 |
| Nos. of Spindle | - | 4 |
| Milling Spindle Speed | rpm | 500-2000 |
| Drilling Spindle Speed | rpm | 500-2000 |
SPINDLE (OPTIONAL)
| Milling Spindle Nose | - | BT-50 |
| Drilling Spindle Nose | - | BT-40 |
| A.C Induction Spindle Motor Power-2Nos. | KW | 7.5 |
| Nos. of Spindle | - | 4 |
| Milling Spindle Speed | rpm | 500-2000 |
| Drilling Spindle Speed | rpm | 500-2000 |
AXIS
| Number of Axis | - | 4 |
| Servo Motor (Milling Axis) | Nm | 12 |
| Servo Motor (Drilling Axis) | Nm | 8 |
| LM Guideways (Milling Axis) | mm | 35 |
| LM Guideways (Drilling Axis) | mm | 45 |
| All axis Ball screw | mm | 32 X 10 |
Accuracy
| Positioning | mm | 0.015 |
| Repeatability | mm | ±0.005 mm |
Other Data
| Height | mm | 2200 |
| Floor Scale ( L x W ) | mm | 5800 x 2000 |
| Basic Machine Weight (Approx.) | Kg | 5800 |
Standard Accessories
- Servo Motor With Incremental Encoder
- Cartridge Type Spindle
- Hydraulic Powerpack With 1.5 HP Motor
- Centralized And Programmable Lubrication
- Self Centering Type Clamping Device
- Auto Coolant
Optional Accessories
- Auto Door
- Patrol Light
- Stabilizer
- Chip Conveyor
- All Possible Customization
Control System Accessories
- RS-232 Serial Interface Port
- Feed Rate Override
- Manual Data Input
- 2 Axis Simultaneous
- Circular Interpolation
- Thread Cutting Cycle
- Electronic Hand Wheel
- Constant Surface Speed Control
- Part Programming Storage and Editing
- Direct Drawing Dimension Programmimg
